Halogen Sensor

Price 1849.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Halogen Sensor Specification

Application
Street Light Sensor

Features
Weatherproof, instant switch, adjustable lux

Measurement Range
2-100 Lux

IP Rating
IP65

Wireless
No

Cable Length
No Wire Inch (in)

Signal Type
Other

Mounting Type
Pole mount

Sensitivity
Adjustable

Interface
Wired connection

Sensor Type
Light Dependent Resistor (LDR)

Response Time
Instant switching Seconds

Operating Temperature
-20~+40 Celsius (oC)

Power Consumption
0.5 Ampere

Product Type
Halogen Sensor

Input
220-240V/AC

Output
Switch signal

Function
Light sensing & switching

Usage
Automatic street light control

Accuracy
High (LDR-based) gm

Resolution
Adjustable Lux detection

Voltage
220-240V/AC Volt (v)

Weight
1 Kilograms (kg)

Rated Voltage
220-240V/AC Volt (V)

Warranty
1 Year

Material
ABS Plastic

Power Source
220-240 V AC

Delay Time
Instant

Load Rating
20 A

Phase
Single phase

Power Frequency
50 Hz

Switch Type
LDR based

Ambient Light
<2-100 LUX adjustable

Rated Load Current
20 A

Model
1L-PC03

Halogen Sensor Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Units Per Month

Delivery Time
3 Days

Main Domestic Market
All India

About Halogen Sensor

Halogen sensors are Halogen Light or LED High Watt Focus light connected with PIR Motion Sensors, when some moving object comes in the range of PIR Sensor, the system gets activated and lights ON the Halogen or LEDs. When the object moves out of range after preset time the light switches OFF. These sensors lights are very effective for security purpose. Halogen Sensors are a great energy Saving device, and very effective for Security purpose, to frighten away unwanted intruders.
